This Articulating Boom Lift has the smallest storage space in its class and convenient transportation performance, giving it an ultra-high carrying capacity.Σ-shaped boom and 5 m turning radius enable agile work in tight spaces. A 48 V/420 Ah battery, four-wheel AC drive with steering differential and 45° gradeability deliver long endurance and smooth, stable power. Zero-emission, low-noise operation makes it ideal for indoor and clean-site use.
This boom articulating lift Ideal for construction and municipal services—bridge upkeep, power‐line installation and general maintenance across challenging terrain. Equally at home in public venues like airports, train stations, shopping centers and stadiums for high‐altitude tasks. Excels in shipyards, warehouse operations and other confined, obstacle‐filled sites requiring precise, efficient access.
| Model | MY16E | MY18E | MY20E | MY22E |
| Specifications | ||||
| Max.Working height | 16.58m | 18m | 20m | 22m |
| Max.Platform height | 14.58m | 16m | 18m | 20m |
| Max.up and over clearance | 7.86m | 7.86m | 11.6m | 12.9m |
| Max.Working radius | 8.45m | 10m | 8.2m | 8.54m |
| A Length -stowed | 6.85m | 7.68m | 8.9m | 8.9m |
| B Height -stowed | 2.32m | 2.32m | 2.53m | 2.53m |
| C Width | 2.32m | 2.32m | 2.45m | 2.45m |
| D Platform width | 0.76m | 0.76m | 0.9m | 0.9m |
| E Platform length | 1.83m | 1.83m | 2.4m | 2.4m |
| Wheelbase | 2.36m | 2.36m | 2.5m | 2.5m |
| Ground clearance-center | 0.3m | 0.3m | 0.33m | 0.33m |
| Productivity | ||||
| Max.Lift capacity | 256kg/350kg | 256kg/350kg | 250kg | 250kg |
| Number of platform occupants | 2/3 | 2/3 | 2 | 2 |
| Platform rotation | ±80° | ±80° | ±80° | ±90° |
| Turntable rotation | 355° | 355° | 355° | 355° |
| Drive speed-stowed | 0-5.2km/h | 0-5.2km/h | 0-6km/h | 0-6km/h |
| Gradeability -stowed | 30% | 30% | 45% | 45% |
| Max.Working angle (Tilt sensor activation) | 5° | 5° | 5° | 5° |
| Turning radius (outside) | 4.7m | 4.7m | 5.4m | 5.4m |
| Drive and steer | 2*2 | 2*2 | 4*4 | 4*4 |
| Weight | 7250kg | 8100kg | 8550kg | 9000kg |
| Power(Diesel engine selection) | ||||
| Battery | 48V/300AhLi | 48V/300AhLi | 48V/420Ah | 48V480Ah |
| Control voltage | 12VDC | 12VDC | 12VDC | 12VDC |
| Pump motor | 7kw | 7kw | 13 kw | 13kw |
| Drive motor | 2*3.3kw | 2*3.3kw | 4*9kw | 4*9kw |
| Compliant with standards | EN280 GB/T 25849 | EN280 GB/T 25849 | EN280 GB/T 25849 | EN280 GB/T 25849 |
